10A PWM dc motor controller forward and backward linear actuator governor speed control self-reset 6V/12V/24V

$15.93 USD
$19.00 USD $15.93 USD
Sale Sold out
Shipping calculated at checkout.

SPECIFICATIONS

10A PWM dc motor controller forward and backward linear actuator governor speed control self-reset 6V/12V/24V

Motor Type: DC Motor

Model Number: pwm

The PWM controller must be loaded with equipment in order to work properly. Please do not test without load.

Working voltage : DC 6V-30V
Maximum current : 10A
Speed scope : 0%-100%
Speed regulation mode : Potentiometer
Output voltage : Linearity under load
Clockwise or anticlockwise : Support
Control frequency : 15KHz
Speed control type : adjust flow
